PROFESSIONAL-LINE XR electric front-loader up to 1,320°C

The KITTEC PROFESSIONAL-LINE front-loaders in the XR model series are characterised by being heated using heating elements in grooved bricks. The coils are integrated in the wall structure, where they are well protected.

5-sided heating from the rear wall, the sides, the door and the base provides optimum all-round temperature distribution. We have consciously decided to use a kiln housing made from rust-proof stainless steel, since all bright components reflect the heat. Not only are the side walls made from stainless steel, but also the entire kiln housing, including the frame! Additional rear ventilation optimises the best insulation characteristics. The icing on the cake in the truest sense of the word is the stainless steel frame on top of the front-loader with integrated perforated sheet metal. You can put your damp items on here to dry before bisque firing them in the kiln.

Features of model series XR:

Housing and frame completely made from stainless steel

Pairs of legs with adjustable height (not with XR 1060)

Hearth air inlet slide valve including drip tray

Adjustable door lock (optionally with lockable eyelet)

Heating elements in grooved bricks

Sustainable energy-saving package NewGen ESP

Further features of model series XR:

Optimum heat distribution thanks to 5-sided heating
Adjustable door hinges
Drying shelf with integrated perforated sheet metal on top of the kiln
Stable SiC ceiling plate – no contamination from above
SiC bottom cover for the heating elements with a maximum of thermal conductivity
Continuous mortar-free brick lining reduces cracking
Extremely solid lightweight refractory brick ASTM 26 in regions with considerable mechanical stress
Wide door opening angle for easy loading (approx. 150°)
Bypass exhaust air nozzle on the right side, condensation-proof
Customised products by request

Optionally available:

Inspection hole (including bung)

Transport castors (MASSIV up to 1000 kg)

Loading rack

Further options for model series XR:

Door hinge and exhaust air on the left, control on the right
Exhaust flap control (only with TC 505, 507, 705 or 707)
Supply air flap control (only with TC 505, 507, 705 or 707)
2-zone controller (only with TC 505, 507, 705 or 707)
3-zone controller (only with TC 505, 507, 705 or 707)
Cooling fan, manual or automatic (only with TC 505, 507, 705 or 707)
Different controllers available
Maximum temperature 1,350 °C
Bricks, heating elements and insulation designed for 1,350 °C
Solid state semiconductor relay (noiseless)
An electronic semiconductor relay is used instead of the electric contactor, allowing noiseless switching procedures during firing.
Levelling feet for compensating for floor unevenness
Flexible exhaust pipe

KITTEC PROFESSIONAL-LINE model series XR:

Modell	Form	Firing chamber width [mm]	Firing chamber depth [mm]	Firing chamber height [mm]	Volume [l]	External width [mm]	External depth [mm]	External height incl. base [mm]	Max. temperature [°C]	Power [kW]	Voltage [V]	Current [A]	Weight [kg]
XR 100	rectangular	410	500	500	103	700	910	1420-1780	1320	8,5	400 3N~	3x13 CEE16	210
XR 150	rectangular	430	560	620	149	720	970	1420-1660	1320	11	400 3N~	3x16 CEE16	260
XR 190	rectangular	480	580	680	189	770	990	1480-1720	1320	14	400 3N~	3x20 CEE32	290
XR 230	rectangular	480	720	680	235	770	1130	1480-1720	1320	17	400 3N~	3x25 CEE32	320
XR 310	rectangular	550	720	800	317	840	1130	1600-1840	1320	22	400 3N~	3x32 CEE32	345
XR 380	rectangular	610	780	800	381	900	1190	1600-1840	1320	27	400 3N~	3x40 CEE63	395
XR 520	rectangular	660	810	980	524	950	1220	1660-1780	1320	34	400 3N~	3x50 CEE63	445
XR 680	rectangular	730	960	980	687	1020	1370	1660-1780	1320	43	400 3N~	3x63 CEE63	530
XR 780	rectangular	730	1040	1040	790	1020	1450	1720-1840	1320	52	400 3N~	3x76	580
XR 1060	rectangular	810	1040	1250	1053	1100	1450	1810	1320	65	400 3N~	3x95	745

All data subject to technical change without notice.

We offer matching furniture sets, tools and additional equipment for KITTEC PROFESSIONAL LINE kilns. Should you have questions about this model series or wish to get more information or customized advice, please feel free to contact us. We will get back to you shortly.
